24V Hydraulic Recovery Winch for Boat and Forestry Crane for Winching Applications
|
24V Hydraulic Recovery Winch for Boat and Forestry Crane for Winching Applications
| Place of Origin | HENAN |
| Brand Name | BALANCE |
| Certification | CE ISO |
| Model Number | BST20 |
Product Details
Maximum Lifting Height:
25 M, 30 M, 6 M, 60m
Material:
Stainless Steel, Steel, Plastic, Carbon Steel
Rope Material:
Stainless Steel
Rope Type:
Steel Wire, Synthetic, Nylon
Wire Rope Diameter:
12, 12.5, 13, 26, 24, 22
Application:
Boat
Controller Cord Length:
10ft, 15 Ft, 20ft
Customized Support:
OEM
End Type:
D-Ring, Chain Extension, Flat-Hook, Wire-Hook
Product Type:
Remote Control, Hook, Handle
Remote Control Type:
Remote And Wired Control Combo, Wired Remote, Wireless Remote
Rope Length:
24 M, 20 M, 50 Meters
Standard:
CVSA, Wstda, FMCSA
Strap Length:
50ft, 100ft, 60 Ft
Strap Width:
4 In, 2 In, 3 In
Voltage:
24 V, 12 V, 120 V, Other
Warranty:
1 Year
Winch Bar Design:
Standard, Combination, Ergonomic
Winch Mounting Location:
Bottom, Sliding Track, Bolt-On
Product Name:
Hydraulic Winch
Capacity:
2000-13500lbs
Color:
Customer Requirement
Motor:
Hydraulic Motor
Control:
Remote Switch
Brake:
Independent Hydraulic Brake
Pulling Speed:
Fast
Packing:
Wooden Case Packing
Power:
710 W
Highlight:
24V hydraulic recovery winch
,boat crane winching equipment
,forestry crane winch 24V
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
$389-510 / set
Product Description
Products Description
fast speed hydraulic winch: For hydraulic winching applications,we are professional . Powerful hydraulic motors allow for extended duty. Hardened steel gear trains deliver efficient and reliable operation plus fast line speeds. Like their electric cousins, these products comply with worldwide quality and safety standards.
product superiority:
- Heavy duty, high-flow hydraulic motor
- Standard roller tensioner and drum brake provide optimal rope winding
- Mechanically locked clutch with smooth action.
- Efficient planetary gear design allows for long-term lubrication with grease
- Easy access and servicing; all internal components are available as complete assemblies
- Large drum diameter for longer wire rope life with less kinking; SAE J706 compliment
- Automatic, spring applied disc brake; highly reliable and robust; complies fully with ISO CE standard
Product Paramenters
| Product | Hydraulic hoisting winch |
| Model | DQ5B30E |
| Line pull capacity (1st layer) | 3 ton |
| Pulling force (4th layer) | 30 KN |
| Drum output torque | 5918 Nm |
| Wire rope capacity | 145 m |
| Wire rope diameter | 12.5 mm |
| Drum diameter | 330 mm |
| Drum width | 450 mm |
| Rope tensioner | Optional spring |
| Application | hoisting works for truck crane, wrecker, recovery truck, tow truck, self loader platform, etc |
